Propane system components
5.2
5/8"
V25x70
28U
5.1
7/8"
5/8"
1/2"
8.4
Propane system enclosure (zone 2)
(LxWxH = 1500x1000x800)
-14°C
Brine
4.1
1"
28U
Propane system
13/8"
7/8"
15/8"
15/8"
13/8"
8.3
14.1
13/8"
B12Mx70
4.3
13/8"
13/8"
13/8"
13/8"
7/8"
6.1
6.2
13/8"
6.2
7/8"
7/8"
B27x70
7/8""
8.2
7.2
11/8"
4.0
11/8"
-10°C
V27x80
-14°C
7/8"
4.2
7/8""
10
8.1
8.0
Danfoss components for propane system, Fakta Beder (special agreement with Danfoss)
Pos. no.
Number
Description
Order no.
Approved
8
1
SFV 15 T 318 safety valve ½", weld, w/nitrile
2416+15800
OK
8.1
1
GBCs, stop valve 7/8"
009G502500
OK
10
2
DCR 0487 Filter house 3/4", weld, 1.2 litres
023U105100
OK
10
2
DN compact insert
023U408000
OK
9
2
SGN sight glass, solder, 22S u/u
014-018600
OK
8.2
1
GBCs, stop value (fill)
009G502000
OK
8.3
1
EVR 10 solenoid valve 5/8"
032F121400
OK
8.4
1
EVR 6 solenoid valve 1/2"
032F120900
OK
8.3
1
Coil IP67 24 V
018Z670700
OK
8.4
1
Coil IP67 24 V
018Z670700
OK
6.1, 6.2
2
Pressure switch KP17B double bellows 6 mm, solder, w/gold contacts
As
06-127400
OK
6.1, 6.2
2
IP 55 encapsulation for KP double
060-035000
OK
Soldering nipple 1/4" flare for 1/4", solder
023U800200
OK
16
2
MP 55 oil differential pressure switch without time relay
060B029900
OK
8.2
3
Stop valve GBC 6s manometer
009G502000
OK
Propane system control
1
AKC 25H1 compressor control
084B201800
1
AKS 32 pressure transmitter, 1-12 bar G 3/8" A
060G200500
1
AKS 32 pressure transmitter, 1-34 bar G 3/8" A
060G200700
2
Soldering nipple G 3/8", solder
017-436800
2
AKS 21 Pt 1000 temperature sensor
084N200700
2
AKS 32 pressure transmitter, 1-12 bar G 3/8" A
060G200500
1
Special AKC24W controller
2
AKS 11 Pt 1000 temperature sensor
084N000500
2
Soldering nipple G 3/8", solder
017-436800
2
AKS25W4 immersion pipe temperature sensor 1/2"
084N206000
1
ESMT outside temperature sensor
087B116400
|
